Fiber assemblies built to order.
OM3 and OM4 multimode, OS2 single-mode. LC and ST connectors, 1 to 50 metres. Every cord is tested to GR-326 and IEC 61300 before it ships, and the measurement travels with it.
- Tested per cord
- Bulk from 100 units
- Custom lengths and labels
LC uniboot duplex, 2.0 mm jacket, UPC polish — shown in all three grades.
Three grades, one tolerance
OM3 multimode
Aqua jacket, 50/125 µm. The default inside a row — server to top-of-rack, switch to patch panel.
- 10G-SR
- 300 m
- 40G-SR4
- 100 m
- 100G-SR4
- 70 m
OM4 multimode
Magenta jacket, bend-insensitive. The same connectors as OM3, with headroom when the hall is long.
- 10G-SR
- 400 m
- 40G-SR4
- 150 m
- 100G-SR4
- 150 m
OS2 single-mode
Yellow jacket, 9/125 µm. Between buildings, out to the carrier, and wherever wavelengths are shared.
- 10G-LR
- 10 km
- 100G-LR4
- 10 km
- CWDM / DWDM
- ready
Why the tolerance matters
A link budget has no slack to give away. Two tenths of a decibel per mating, across four matings, is most of what a 100 metre run can afford.
So every FeatherOptics cord is measured before it ships — insertion loss, return loss and endface geometry, recorded against the part number and released with the shipment. Not a sample from the reel. Every cord.
≤ 0.20 dB
Insertion loss
≥ 50 dB
Return loss
1,000+
Mating cycles
100
Minimum order
Tested and documented to
GR-326
Telcordia patch cord
TIA-568
Structured cabling
IEC 61300
Connector test methods
RoHS
Restricted substances
Have a bill of materials? Send it over.
Paste your part numbers and quantities. We come back with pricing, lead time and any substitution worth knowing about.
